Peli-Hardigg™ Single Lid case sizes

Peli Single Lid case dimensions and technical info

With a vast number of sizes, you may find it challenging to select the best Peli-Hardigg™ Single Lid case sizes for your business.

Peli Single Lid cases are available in well over 250 sizes. This range of options includes various formats, including cube, flat, long, tower, and trunk-type cases. Single Lid cases are available in nine colours: black, grey, white, yellow, orange, red, blue, olive green, and desert tan.

At GWP Protective, we can supply and customise any of the Peli Hardigg roto moulded cases. Our case specialists are also happy to provide free, impartial advice on the best case size and options for your specific requirements.

Peli-Hardigg™ Single Lid size chart

Cube type Peli Single Lid case sizes

Ref.	Internal (L x W x H)	External (L x W x H)	Lid / Base	Weight
AL1010-0904	252 x 254 x 322 mm	328 x 330 x 365 mm	221 / 102 mm	4.4 kg
AL1212-0405	305 x 305 x 237 mm	381 x 381 x 280 mm	107 / 130 mm	4.4 kg
AL1212-0604	305 x 305 x 262 mm	381 x 381 x 305 mm	160 / 102 mm	5 kg
AL1212-0605	305 x 305 x 290 mm	381 x 381 x 330 mm	160 / 130 mm	5.1 kg
AL1413-0505	368 x 333 x 262 mm	445 x 409 x 305 mm	129 / 133 mm	6.1 kg
AL1413-1005	368 x 333 x 392 mm	445 x 409 x 435 mm	259 / 133 mm	7.5 kg
AL1414-0705	356 x 359 x 303 mm	432 x 435 x 346 mm	171 / 132 mm	6.6 kg
AL1616-0412	400 x 403 x 408 mm	476 x 479 x 449 mm	98 / 309 mm	8.1 kg
AL1616-0512	400 x 403 x 447 mm	476 x 479 x 487 mm	138 / 309 mm	8.4 kg
AL1616-1004	400 x 403 x 349 mm	476 x 480 x 392 mm	251 / 98 mm	7.8 kg
AL1616-1005	400 x 403 x 381 mm	476 x 480 x 424 mm	251 / 130 mm	8 kg
AL1616-1204	400 x 403 x 386 mm	476 x 480 x 429 mm	288 / 98 mm	8.1 kg
AL1616-1205	400 x 403 x 418 mm	476 x 480 x 461 mm	288 / 130 mm	8.4 kg
AL1717-0909	432 x 432 x 453 mm	508 x 508 x 496 mm	225 / 229 mm	8.5 kg
AL1814-1504	457 x 371 x 479 mm	533 x 447 x 522 mm	379 / 100 mm	8.8 kg
AL1814-1505	457 x 371 x 511 mm	533 x 448 x 554 mm	379 / 132 mm	9.3 kg
AL2020-1305	505 x 505 x 460 mm	581 x 581 x 503 mm	328 / 132 mm	11.7 kg
AL2221-0414	571 x 535 x 461 mm	647 x 611 x 513 mm	99 / 362 mm	13.7 kg
AL2221-0419DE	571 x 535 x 600 mm	647 x 611 x 643 mm	102 / 498 mm	14.5 kg
AL2221-1204	572 x 535 x 402 mm	648 x 611 x 444 mm	306 / 95 mm	11.9 kg
AL2221-1205	572 x 535 x 433 mm	648 x 611 x 476 mm	306 / 127 mm	12.4 kg
AL2221-1214	571 x 535 x 668 mm	647 x 611 x 643 mm	306 / 362 mm	14.4 kg
AL2221-1802	571 x 535 x 530 mm	647 x 611 x 573 mm	473 / 57 mm	14.5 kg
AL2221-1804	571 x 535 x 568 mm	647 x 611 x 611 mm	473 / 95 mm	15.1 kg
AL2221-1805	571 x 535 x 600 mm	647 x 611 x 643 mm	473 / 127 mm	15.5 kg
AL2318-1705	581 x 455 x 566 mm	657 x 531 x 615 mm	436 / 130 mm	13.2 kg
AL2423-0911	628 x 590 x 508 mm	705 x 666 x 589 mm	222 / 286 mm	14.4 kg
AL2423-1111	628 x 590 x 559 mm	705 x 666 x 627 mm	273 / 286 mm	14.7 kg
AL2624-0524	660 x 612 x 746 mm	736 x 686 x 829 mm	136 / 610 mm	19.1 kg
AL2624-1213	662 x 609 x 634 mm	738 x 686 x 728 mm	301 / 333 mm	17.3 kg
AL2624-1805	662 x 609 x 581 mm	738 x 686 x 676 mm	452 / 129 mm	17.5 kg
AL2727-0414	686 x 686 x 454 mm	762 x 762 x 509 mm	92 / 362 mm	17.5 kg
AL2727-0514	686 x 686 x 489 mm	762 x 762 x 544 mm	127 / 362 mm	17.6 kg
AL2727-0914	686 x 686 x 585 mm	762 x 762 x 641 mm	224 / 362 mm	18.6 kg
AL2727-1404	686 x 686 x 457 mm	762 x 762 x 512 mm	359 / 98 mm	16.8 kg
AL2727-1405	686 x 686 x 485 mm	762 x 762 x 541 mm	359 / 127 mm	17.5 kg
AL2727-1409 AC	686 x 686 x 593 mm	762 x 762 x 649 mm	359 / 235 mm	18.6 kg
AL2727-1414	686 x 686 x 720 mm	762 x 762 x 776 mm	359 / 362 mm	20.5 kg
AL2727-2304	686 x 686 x 676 mm	762 x 762 x 731 mm	578 / 98 mm	19.6 kg
AL2727-2305	686 x 686 x 705 mm	762 x 762 x 760 mm	578 / 127 mm	19.6 kg
AL2727-2309	686 x 686 x 812 mm	762 x 762 x 868 mm	578 / 235 mm	22.2 kg
AL2727-2704	686 x 686 x 783 mm	762 x 762 x 839 mm	685 / 98 mm	21.6 kg
AL2727-2705	686 x 686 x 812 mm	762 x 762 x 868 mm	685 / 127 mm	22.2 kg
AL2825-1612	724 x 635 x 731 mm	800 x 711 x 787 mm	419 / 312 mm	20.7 kg
AL3428-1025	863 x 698 x 879 mm	939 x 774 x 933 mm	249 / 630 mm	29.1 kg
AL3434-1228	873 x 873 x 1041 mm	949 x 949 x 1130 mm	318 / 724 mm	39.5 kg
AL3434-2807	873 x 873 x 887 mm	949 x 949 x 976 mm	703 / 184 mm	30.3 kg
AL3834-1617	968 x 866 x 838 mm	1044 x 420 x 986 mm	400 / 438 mm	39.2 kg
AL3834-1628	968 x 866 x 1119 mm	1044 x 942 x 1266 mm	400 / 719 mm	53.5 kg
AL4141-0826	1041 x 1041 x 863 mm	1117 x 1117 x 901 mm	210 / 654 mm	51.7 kg
AL4141-0836	1041 x 1041 x 1111 mm	1117 x 1117 x 1155 mm	210 / 902 mm	55.8 kg

Flat type Peli Single Lid case sizes

Ref.	Internal (L x W x H)	External (L x W x H)	Lid / Base	Weight
AL1212-0404	305 x 305 x 209 mm	381 x 381 x 251 mm	107 / 102 mm	4.3 kg
AL1616-0404	400 x 403 x 197 mm	476 x 480 x 240 mm	98 / 98 mm	5.7 kg
AL1616-0405	400 x 403 x 228 mm	476 x 480 x 272 mm	98 / 130 mm	6.2 kg
AL1616-0504	400 x 403 x 236 mm	476 x 480 x 279 mm	138 / 98 mm	6.3 kg
AL1616-0505	400 x 403 x 268 mm	476 x 480 x 310 mm	138 / 130 mm	6.6 kg
AL1814-0504	457 x 371 x 231 mm	533 x 448 x 274 mm	132 / 100 mm	6.5 kg
AL1818-0603	455 x 455 x 242 mm	531 x 531 x 286 mm	162 / 81 mm	7.5 kg
AL2013-0403	505 x 330 x 178 mm	581 x 406 x 221 mm	102 / 76 mm	6.1 kg
AL2013-0903	505 x 330 x 311 mm	581 x 406 x 354 mm	235 / 76 mm	7.6 kg
AL2015-0503	501 x 330 x 178 mm	578 x 473 x 241 mm	129 / 70 mm	7.5 kg
AL2216-0503	559 x 406 x 210 mm	635 x 483 x 254 mm	133 / 76 mm	7.9 kg
AL2216-0505	559 x 406 x 267 mm	635 x 483 x 310 mm	133 / 133 mm	8.4 kg
AL2221-0402	572 x 535 x 156 mm	648 x 611 x 211 mm	99 / 57 mm	9.6 kg
AL2221-0404	572 x 535 x 194 mm	648 x 611 x 249 mm	99 / 95 mm	10.2 kg
AL2221-0405	572 x 535 x 226 mm	648 x 611 x 279 mm	99 / 127 mm	10.6 kg
AL2221-0602	572 x 535 x 222 mm	648 x 611 x 265 mm	165 / 57 mm	10.3 kg
AL2221-0604	572 x 535 x 260 mm	648 x 611 x 303 mm	165 / 95 mm	10.9 kg
AL2221-0605	572 x 535 x 292 mm	648 x 611 x 334 mm	165 / 127 mm	11.2 kg
AL2221-0614	571 x 535 x 527 mm	647 x 611 x 568 mm	165 / 362 mm	13.3 kg
AL2221-1202	572 x 535 x 363 mm	648 x 611 x 406 mm	306 / 57 mm	11.3 kg
AL2423-0503	628 x 590 x 203 mm	705 x 666 x 294 mm	119 / 84 mm	10.6 kg
AL2423-0504	628 x 590 x 218 mm	705 x 666 x 308 mm	119 / 99 mm	10.9 kg
AL2423-0506	628 x 590 x 278 mm	705 x 666 x 331 mm	119 / 159 mm	11.3 kg
AL2423-0511	628 x 590 x 404 mm	705 x 666 x 496 mm	119 / 286 mm	13.7 kg
AL2423-0903	628 x 590 x 306 mm	705 x 666 x 386 mm	222 / 84 mm	11.3 kg
AL2423-0904	628 x 590 x 321 mm	705 x 666 x 401 mm	222 / 99 mm	11.6 kg
AL2423-0906	628 x 590 x 381 mm	705 x 666 x 462 mm	222 / 159 mm	12.7 kg
AL2423-1103	628 x 590 x 357 mm	705 x 666 x 425 mm	273 / 84 mm	12.4 kg
AL2423-1104	628 x 590 x 372 mm	705 x 666 x 440 mm	273 / 99 mm	12.7 kg
AL2423-1106	628 x 590 x 432 mm	705 x 666 x 500 mm	273 / 159 mm	13.4 kg
AL2624-0503	660 x 612 x 222 mm	736 x 686 x 305 mm	136 / 86 mm	10.9 kg
AL2624-0505	660 x 612 x 265 mm	736 x 686 x 353 mm	136 / 129 mm	12.7 kg
AL2624-0513	660 x 612 x 469 mm	736 x 686 x 557 mm		kg
AL2624-0803	660 x 612 x 290 mm	736 x 686 x 368 mm		kg
AL2624-0805	662 x 609 x 333 mm	736 x 686 x 427 mm	205 / 129 mm	14.2 kg
AL2624-1203	660 x 612 x 387 mm	736 x 686 x 469 mm	301 / 86 mm	14.1 kg
AL2727-0404	686 x 686 x 190 mm	762 x 762 x 246 mm	92 / 98 mm	13.8 kg
AL2727-0405	686 x 686 x 219 mm	762 x 762 x 274 mm	92 / 127 mm	14.5 kg
AL2727-0409	686 x 686 x 327 mm	762 x 762 x 382 mm	92 / 235 mm	15.6 kg
AL2727-0504	686 x 686 x 225 mm	762 x 762 x 281 mm	127 / 98 mm	13.9 kg
AL2727-0505	686 x 686 x 254 mm	762 x 762 x 310 mm	127 / 127 mm	14.5 kg
AL2727-0509	686 x 686 x 362 mm	762 x 762 x 417 mm	127 / 235 mm	15.7 kg
AL2727-0904	686 x 686 x 322 mm	762 x 762 x 377 mm	224 / 98 mm	15 kg
AL2727-0905	686 x 686 x 350 mm	762 x 762 x 406 mm	224 / 127 mm	15.6 kg
AL2727-0909	686 x 686 x 458 mm	762 x 762 x 514 mm	224 / 235 mm	16.8 kg
AL3018-0402	755 x 454 x 181 mm	832 x 530 x 227 mm	114 / 67 mm	9.3 kg
AL3018-0403	755 x 454 x 206 mm	832 x 530 x 252 mm	114 / 92 mm	9.6 kg
AL3018-0405	755 x 454 x 248 mm	832 x 530 x 294 mm	114 / 133 mm	9.8 kg
AL3022-0705	762 x 560 x 309 mm	838 x 639 x 355 mm	178 / 132 mm	16.7 kg
AL3428-0604	863 x 698 x 251 mm	939 x 774 x 310 mm	155 / 95 mm	17.6 kg
AL3428-0608	863 x 698 x 363 mm	939 x 774 x 422 mm	155 / 208 mm	19.3 kg
AL3434-1207	873 x 873 x 501 mm	949 x 949 x 569 mm	318 / 184 mm	25 kg
AL3535-1605	901 x 901 x 530 mm	978 x 978 x 614 mm	400 / 130 mm	30.8 kg
AL3620-0504	911 x 504 x 229 mm	987 x 581 x 274 mm	127 / 102 mm	10.6 kg
AL3620-0505	911 x 504 x 257 mm	987 x 581 x 312 mm	127 / 130 mm	11.6 kg
AL3627-0805	911 x 686 x 329 mm	987 x 762 x 422 mm	199 / 130 mm	19.8 kg
AL3633-0405	922 x 846 x 258 mm	998 x 922 x 301 mm	114 / 144 mm	19.5 kg
AL4141-0808	1041 x 1041 x 416 mm	1117 x 1117 x 457 mm	203 / 203 mm	31.8 kg
AL4532-0506	1143 x 812 x 286 mm	1219 x 889 x 368 mm	133 / 152 mm	28.7 kg
AL5415-1026	1371 x 403 x 924 mm	1447 x 479 x 952 mm	254 / 645 mm	40.6 kg
AL5545-0605	1409 x 1155 x 335 mm	1485 x 1231 x 381 mm	160 / 130 mm	33.5 kg
BL6752-0805	1712 x 1317 x 334 mm	1788 x 1393 x 474 mm	204 / 130 mm	65.8 kg
CL1109-0303	279 x 225 x 152 mm	333 x 276 x 208 mm	76 / 76 mm	2.4 kg
CL1412-0502	375 x 301 x 189 mm	428 x 352 x 214 mm	125 / 64 mm	4.3 kg
CL1713-0403	429 x 327 x 187 mm	482 x 378 x 230 mm	111 / 76 mm	3.1 kg
CL2012-0902	512 x 298 x 296 mm	566 x 349 x 339 mm	233 / 64 mm	5.5 kg

Long Peli Single Lid case sizes

Ref.	Internal (L x W x H)	External (L x W x H)	Lid / Base	Weight
AL13115-0805	3326 x 381 x 336 mm	3402 x 457 x 456 mm	210 / 127 mm	44 kg
AL2909-0605	724 x 216 x 286 mm	800 x 292 x 329 mm	152 / 133 mm	7.2 kg
AL3418-0505	868 x 457 x 267 mm	944 x 533 x 316 mm	133 / 133 mm	12.2 kg
AL4018-1003	1016 x 457 x 335 mm	1092 x 533 x 375 mm	259 / 76 mm	16.3 kg
AL4119-0704	1030 x 485 x 345 mm	1110 x 561 x 396 mm	181 / 114 mm	14.5 kg
AL4714-0403	1190 x 357 x 178 mm	1266 x 433 x 221 mm	102 / 76 mm	12 kg
AL4714-0405	1190 x 357 x 235 mm	1266 x 433 x 278 mm	102 / 133 mm	12.3 kg
AL4714-0503	1190 x 357 x 209 mm	1266 x 433 x 252 mm	133 / 76 mm	12.5 kg
AL4714-0505	1190 x 357 x 267 mm	1266 x 433 x 310 mm	133 / 133 mm	13.4 kg
AL4915-1105	1244 x 376 x 413 mm	1320 x 452 x 468 mm	279 / 133 mm	18.1 kg
AL5616-0604	1433 x 413 x 256 mm	1509 x 489 x 324 mm	149 / 107 mm	19.2 kg
AL5910-0604	1500 x 252 x 262 mm	1576 x 328 x 311 mm	157 / 105 mm	14.3 kg
AL6815-1005	1727 x 387 x 389 mm	1803 x 463 x 435 mm	257 / 132 mm	26.5 kg
AL6912-1003	1761 x 305 x 358 mm	1837 x 381 x 413 mm	266 / 91 mm	19.1 kg
AL7007-0403	1784 x 178 x 178 mm	1860 x 254 x 248 mm	102 / 76 mm	13.6 kg
AL7819-0805	2003 x 493 x 337 mm	2050 x 569 x 380 mm	210 / 128 mm	27.6 kg
AL7819-0808	2003 x 493 x 413 mm	2050 x 569 x 456 mm	210 / 204 mm	28 kg
BL11433-0527	2894 x 838 x 828 mm	2996 x 939 x 871 mm	137 / 692 mm	95.3 kg
BL8232-0705	2079 x 811 x 314 mm	2180 x 912 x 427 mm	184 / 130 mm	55.5 kg
BL8232-0905	2079 x 811 x 359 mm	2180 x 912 x 471 mm	229 / 130 mm	58.1 kg
BL8240-1623	2076 x 1016 x 987 mm	2177 x 1117 x 1220 mm	409 / 578 mm	104 kg
BL8537-2906	2164 x 958 x 894 mm	2266 x 1060 x 1005 mm	741 / 153 mm	86.2 kg
BL9024-1113	2310 x 614 x 633 mm	2412 x 716 x 844 mm	295 / 339 mm	66.8 kg
BL9836-1105	2483 x 912 x 409 mm	2585 x 1013 x 528 mm	279 / 130 mm	86.2 kg
CL2406-0303	628 x 168 x 155 mm	682 x 219 x 198 mm	78 / 78 mm	3 kg
CL2407-0404	628 x 190 x 174 mm	682 x 241 x 217 mm	89 / 85 mm	4 kg

Tower type Peli Single Lid case sizes

Ref.	Internal (L x W x H)	External (L x W x H)	Lid / Base	Weight
AL1010-0905	252 x 254 x 354 mm	328 x 330 x 397 mm	221 / 133 mm	4.5 kg
AL1010-1404	252 x 254 x 451 mm	328 x 330 x 494 mm	349 / 102 mm	5.2 kg
AL1010-1405	252 x 254 x 483 mm	328 x 330 x 526 mm	349 / 133 mm	5.6 kg
AL1212-1204	305 x 305 x 388 mm	381 x 381 x 431 mm	286 / 102 mm	5.8 kg
AL1212-1205	305 x 305 x 416 mm	381 x 381 x 459 mm	286 / 130 mm	5.9 kg
AL1212-1504	305 x 305 x 487 mm	381 x 381 x 530 mm	386 / 102 mm	6.7 kg
AL1212-1505	305 x 305 x 516 mm	381 x 381 x 559 mm	386 / 130 mm	6.8 kg
AL1212-1904	305 x 305 x 577 mm	381 x 381 x 620 mm	475 / 102 mm	7.6 kg
AL1212-1905	305 x 305 x 605 mm	381 x 381 x 648 mm	475 / 130 mm	7.7 kg
AL1413-2105	368 x 333 x 660 mm	445 x 409 x 703 mm	527 / 133 mm	8.9 kg
AL1616-1012	400 x 403 x 560 mm	476 x 479 x 601 mm	251 / 309 mm	10.2 kg
AL1616-1212	400 x 403 x 597 mm	476 x 479 x 640 mm	288 / 309 mm	10.5 kg
AL1616-1804	400 x 403 x 562 mm	476 x 480 x 605 mm	464 / 98 mm	9.8 kg
AL1616-1805	400 x 403 x 594 mm	476 x 480 x 637 mm	464 / 130 mm	10 kg
AL1616-1812	400 x 403 x 773 mm	476 x 479 x 816 mm	464 / 309 mm	12.2 kg
AL1814-2204	457 x 371 x 663 mm	533 x 448 x 706 mm	563 / 100 mm	10.6 kg
AL1814-2205	457 x 371 x 695 mm	533 x 448 x 738 mm	563 / 132 mm	11.2 kg
AL2221-1814	571 x 535 x 835 mm	647 x 611 x 878 mm	473 / 362 mm	17.5 kg
AL2221-2802	571 x 535 x 781 mm	647 x 611 x 814 mm	724 / 57 mm	17.5 kg
AL2221-2804	571 x 535 x 809 mm	647 x 611 x 852 mm	714 / 95 mm	18.1 kg
AL2221-2805	571 x 535 x 841 mm	647 x 611 x 884 mm	714 / 127 mm	18.4 kg
AL2221-2814	571 x 535 x 1076 mm	647 x 611 x 1119 mm	714 / 362 mm	17.7 kg
AL2624-0824	662 x 609 x 814 mm	738 x 686 x 908 mm	205 / 610 mm	20.6 kg
AL2624-1224	662 x 609 x 911 mm	738 x 686 x 1005 mm	301 / 610 mm	21.9 kg
AL2624-1813	662 x 609 x 785 mm	738 x 686 x 879 mm	452 / 333 mm	19.7 kg
AL2624-1824	662 x 609 x 1062 mm	738 x 686 x 1155 mm	452 / 610 mm	23.8 kg
AL2624-2703	660 x 612 x 763 mm	736 x 686 x 873 mm	677 / 86 mm	18.6 kg
AL2624-2705	662 x 609 x 806 mm	738 x 686 x 901 mm	677 / 129 mm	20.2 kg
AL2624-2713	662 x 609 x 1010 mm	738 x 686 x 1104 mm	677 / 333 mm	22.4 kg
AL2624-2724	662 x 609 x 1287 mm	738 x 686 x 139 mm	677 / 610 mm	26.4 kg
AL2727-2314	686 x 686 x 939 mm	762 x 762 x 995 mm	578 / 362 mm	24 kg
AL2727-2709AC	686 x 686 x 920 mm	762 x 762 x 975 mm	685 / 235 mm	23.4 kg
AL2727-2714	686 x 686 x 1047 mm	762 x 762 x 1102 mm	685 / 362 mm	25.2 kg
AL3018-3602	755 x 454 x 987 mm	832 x 530 x 1033 mm	921 / 67 mm	19.5 kg
AL3018-3603	755 x 454 x 1012 mm	832 x 530 x 1058 mm	921 / 92 mm	19.9 kg
AL3018-3605	755 x 454 x 1054 mm	832 x 530 x 110 mm	921 / 133 mm	20.1 kg
AL3018-3609	755 x 454 x 1155 mm	832 x 530 x 1201 mm	921 / 235 mm	22.8 kg
AL3434-2828	873 x 873 x 1428 mm	949 x 949 x 1509 mm	703 / 724 mm	32.7 kg
AL4141-0846	1041 x 1041 x 1365 mm	1117 x 1117 x 1409 mm	210 / 1156 mm	59.9 kg

Trunk style Peli Single Lid case sizes

Ref.	Internal (L x W x H)	External (L x W x H)	Lid / Base	Weight
AL1814-0505	457 x 371 x 264 mm	533 x 448 x 306 mm	132 / 132 mm	7.1 kg
AL2017-0706	514 x 436 x 330 mm	590 x 512 x 376 mm	178 / 152 mm	8.7 kg
AL2216-0803	559 x 406 x 290 mm	635 x 483 x 333 mm	214 / 76 mm	8.6 kg
AL2216-0805	559 x 406 x 347 mm	635 x 483 x 390 mm	214 / 133 mm	9.1 kg
AL2216-1203	559 x 406 x 387 mm	635 x 483 x 432 mm	311 / 76 mm	9.6 kg
AL2216-1205	559 x 406 x 445 mm	635 x 483 x 487 mm	311 / 133 mm	10 kg
AL2216-1503	501 x 397 x 456 mm	578 x 473 x 499 mm		kg
AL2313-1004	584 x 330 x 393 mm	660 x 406 x 449 mm	276 / 118 mm	9.2 kg
AL2315-2507	590 x 387 x 825 mm	666 x 463 x 906 mm	644 / 181 mm	14.6 kg
AL2316-0604	597 x 403 x 285 mm	673 x 479 x 341 mm	162 / 124 mm	9 kg
AL2318-1205	581 x 445 x 443 mm	657 x 531 x 492 mm	311 / 132 mm	11.6 kg
AL2412-1505	614 x 305 x 510 mm	690 x 381 x 565 mm	378 / 132 mm	10 kg
AL2414-0509	625 x 370 x 369 mm	701 x 446 x 424 mm	132 / 237 mm	10.7 kg
AL2414-1604	616 x 362 x 511 mm	692 x 438 x 562 mm	408 / 103 mm	10.4 kg
AL2415-0215	616 x 387 x 426 mm	692 x 463 x 481 mm	49 / 377 mm	11.7 kg
AL2417-1505	609 x 432 x 508 mm	686 x 508 x 558 mm	377 / 132 mm	12.4 kg
AL2617-0604	660 x 438 x 251 mm	736 x 514 x 307 mm	156 / 95 mm	10.2 kg
AL2617-1104	660 x 438 x 375 mm	736 x 514 x 430 mm	279 / 95 mm	11.9 kg
AL2624-0813	662 x 609 x 538 mm	738 x 686 x 631 mm		kg
AL2624-1205	662 x 609 x 430 mm	738 x 686 x 525 mm	301 / 129 mm	15.5 kg
AL2624-1803	660 x 612 x 538 mm	736 x 686 x 638 mm	452 / 86 mm	15.9 kg
AL2818-0805	714 x 460 x 336 mm	790 x 536 x 392 mm	206 / 130 mm	12 kg
AL2825-1205	724 x 635 x 450 mm	800 x 711 x 493 mm	321 / 130 mm	17 kg
AL2825-1212	724 x 635 x 633 mm	800 x 711 x 671 mm	321 / 312 mm	20 kg
AL2825-1605	724 x 635 x 549 mm	800 x 711 x 606 mm	419 / 130 mm	17.7 kg
AL2914-0905	733 x 368 x 357 mm	809 x 444 x 406 mm	225 / 132 mm	10.5 kg
AL2914-0906	733 x 368 x 382 mm	809 x 444 x 432 mm	225 / 157 mm	11.1 kg
AL2924-0904	742 x 606 x 338 mm	819 x 682 x 394 mm	237 / 101 mm	13.7 kg
AL3018-0409	755 x 454 x 349 mm	832 x 530 x 395 mm	114 / 235 mm	12.6 kg
AL3018-0802	755 x 454 x 274 mm	832 x 530 x 320 mm	208 / 67 mm	11.3 kg
AL3018-0803	755 x 454 x 300 mm	832 x 530 x 346 mm	208 / 92 mm	11.7 kg
AL3018-0805	755 x 454 x 341 mm	832 x 530 x 387 mm	208 / 133 mm	11.8 kg
AL3018-0809	755 x 454 x 443 mm	832 x 530 x 489 mm	208 / 235 mm	14.6 kg
AL3018-0902	755 x 454 x 304 mm	832 x 530 x 351 mm	238 / 67 mm	12.2 kg
AL3018-0903	755 x 454 x 330 mm	832 x 530 x 376 mm	238 / 92 mm	12.5 kg
AL3018-0905	755 x 454 x 371 mm	832 x 530 x 417 mm	238 / 133 mm	12.6 kg
AL3018-0909	755 x 454 x 473 mm	832 x 530 x 519 mm	238 / 235 mm	15.4 kg
AL3018-1502	755 x 454 x 444 mm	832 x 530 x 490 mm	378 / 67 mm	13.5 kg
AL3018-1503	755 x 454 x 469 mm	832 x 530 x 516 mm	378 / 92 mm	13.8 kg
AL3018-1505	755 x 454 x 511 mm	832 x 530 x 577 mm	378 / 133 mm	14.4 kg
AL3018-1509	755 x 454 x 612 mm	832 x 530 x 658 mm	378 / 235 mm	16.8 kg
AL3018-2302	755 x 454 x 670 mm	832 x 530 x 716 mm	603 / 67 mm	17.2 kg
AL3018-2303	755 x 454 x 695 mm	832 x 530 x 741 mm	603 / 92 mm	18.4 kg
AL3018-2305	755 x 454 x 736 mm	832 x 530 x 782 mm	603 / 133 mm	18.4 kg
AL3018-2309	755 x 454 x 838 mm	832 x 530 x 884 mm	603 / 235 mm	19.5 kg
AL3019-0709	781 x 498 x 431 mm	857 x 574 x 499 mm	194 / 237 mm	18.4 kg
AL3124-1204	798 x 620 x 398 mm	874 x 696 x 492 mm	301 / 97 mm	13.6 kg
AL3124-1604	798 x 620 x 500 mm	874 x 696 x 593 mm	403 / 97 mm	18 kg
AL3226-1404	825 x 676 x 466 mm	901 x 752 x 617 mm	360 / 106 mm	23.8 kg
AL3226-1413	825 x 676 x 688 mm	901 x 752 x 836 mm	360 / 328 mm	27.6 kg
AL3226-1604	825 x 676 x 515 mm	901 x 752 x 622 mm	409 / 106 mm	23.9 kg
AL3226-1613	825 x 676 x 737 mm	901 x 752 x 843 mm	409 / 328 mm	28.3 kg
AL3228-0625	863 x 698 x 785 mm	939 x 774 x 844 mm		kg
AL3232-1412	823 x 823 x 679 mm	900 x 900 x 773 mm	368 / 311 mm	31 kg
AL3418-1005	868 x 457 x 390 mm	944 x 533 x 440 mm	257 / 133 mm	13.9 kg
AL3424-0804	870 x 614 x 312 mm	946 x 690 x 368 mm	203 / 109 mm	15.6 kg
AL3424-0805	870 x 614 x 336 mm	946 x 690 x 392 mm	203 / 133 mm	16.7 kg
AL3424-1204	870 x 614 x 414 mm	946 x 690 x 469 mm	305 / 109 mm	18.1 kg
AL3424-1205	870 x 614 x 438 mm	946 x 690 x 494 mm	305 / 133 mm	19.3 kg
AL3428-0614	863 x 698 x 517 mm	939 x 774 x 576 mm	155 / 364 mm	21.5 kg
AL3428-0625	863 x 698 x 785 mm	939 x 774 x 884 mm	155 / 630 mm	25.9 kg
AL3428-1004	863 x 698 x 344 mm	939 x 774 x 400 mm	249 / 95 mm	22 kg
AL3428-1008AC	863 x 698 x 457 mm	939 x 774 x 513 mm	249 / 208 mm	23 kg
AL3428-1014	863 x 698 x 613 mm	939 x 774 x 669 mm	249 / 364 mm	27.9 kg
AL3620-0510	911 x 504 x 385 mm	987 x 581 x 432 mm	127 / 258 mm	14.7 kg
AL3620-1704	911 x 504 x 536 mm	987 x 581 x 592 mm	435 / 102 mm	18.9 kg
AL3620-1705	911 x 504 x 565 mm	987 x 581 x 620 mm	435 / 130 mm	19.6 kg
AL3620-1710	911 x 504 x 692 mm	987 x 581 x 748 mm	435 / 258 mm	22.9 kg
AL3627-1505	911 x 686 x 508 mm	987 x 762 x 601 mm	378 / 130 mm	22.8 kg
AL3834-1605	968 x 866 x 537 mm	1044 x 942 x 685 mm	400 / 137 mm	32.2 kg
AL4021-0804	1041 x 530 x 279 mm	1117 x 606 x 348 mm	183 / 97 mm	16.8 kg
AL4021-0808	1041 x 530 x 379 mm	1117 x 606 x 447 mm	183 / 196 mm	18.6 kg
AL4024-1305	1012 x 617 x 457 mm	1088 x 693 x 513 mm	324 / 133 mm	22.8 kg
AL4028-1608	1009 x 705 x 600 mm	1085 x 781 x 694 mm	393 / 208 mm	31.8 kg
AL4028-2105	1009 x 705 x 649 mm	1085 x 781 x 742 mm	517 / 132 mm	36.3 kg
AL4532-0515	1143 x 812 x 511 mm	1219 x 889 x 635 mm	133 / 378 mm	36.8 kg
AL4532-1606	1143 x 812 x 546 mm	1219 x 889 x 660 mm	394 / 152 mm	37.2 kg
AL4532-1615	1143 x 812 x 771 mm	1219 x 889 x 890 mm	394 / 378 mm	44.1 kg
AL4824-1404	1234 x 625 x 449 mm	1311 x 701 x 542 mm	351 / 98 mm	26.3 kg
AL4824-1408	1234 x 625 x 557 mm	1311 x 701 x 650 mm	351 / 206 mm	29.3 kg
AL4824-1604	1234 x 625 x 499 mm	1311 x 701 x 593 mm	401 / 98 mm	26 kg
AL4824-1608	1234 x 625 x 607 mm	1311 x 701 x 701 mm	401 / 206 mm	28.9 kg
AL5023-0911	1282 x 592 x 510 mm	1358 x 668 x 597 mm	231 / 279 mm	23.1 kg
AL5040-1204	1273 x 1016 x 403 mm	1349 x 1092 x 484 mm	308 / 95 mm	40.8 kg
AL5040-1212AC	1273 x 609 x 403 mm	1349 x 1092 x 690 mm	308 / 301 mm	46.7 kg
AL5135-0718	1295 x 890 x 640 mm	1371 x 966 x 812 mm	173 / 468 mm	46.9 kg
AL5240-1138	1320 x 1016 x 1244 mm	1396 x 1092 x 1338 mm	279 / 965 mm	64.9 kg
AL5424-2306	1320 x 1016 x 1244 mm	1396 x 1092 x 1338 mm	578 / 155 mm	47.3 kg
AL5430-3006	1368 x 757 x 912 mm	1444 x 833 x 1006 mm	759 / 154 mm	51.7 kg
AL5545-0623AC-HL	1409 x 1155 x 777 mm	1485 x 1231 x 870 mm	205 / 573 mm	71.2 kg
AL5545-2323	1409 x 1155 x 1152 mm	1485 x 1231 x 1245 mm	579 / 573 mm	81.2 kg
AL5733-0916	1444 x 832 x 636 mm	1520 x 908 x 905 mm	230 / 406 mm	56 kg
AL5824-1119	1488 x 612 x 766 mm	1565 x 689 x 860 mm	279 / 487 mm	34.7 kg
AL5834-0128	1480 x 870 x 750 mm	1557 x 946 x 835 mm	41 / 709 mm	57.2 kg
AL5834-0140	1480 x 870 x 1057 mm	1557 x 946 x 1149 mm	41 / 1016 mm	60.8 kg
AL5834-0728	1480 x 870 x 903 mm	1557 x 946 x 987 mm	194 / 709 mm	63 kg
AL5834-0740	1480 x 870 x 1209 mm	1557 x 946 x 1300 mm	194 / 1016 mm	64 kg
AL5924-1018	1504 x 616 x 719 mm	1581 x 692 x 754 mm	257 / 462 mm	33.6 kg
BL8024-3009	2042 x 620 x 996 mm	2144 x 722 x 1112 mm	765 / 232 mm	72.3 kg
CL1713-0408	429 x 327 x 305 mm	482 x 378 x 348 mm	111 / 194 mm	5 kg
CL1715-0904	435 x 378 x 356 mm	489 x 428 x 398 mm	251 / 105 mm	5.7 kg
